Signature VBA: RetVal = object.AddPolyline( VerticesList) object Type:,, The objects this method applies to. Jfuse movie splitter 5.0 - download free apps VerticesList Access: Input-only Type: Variant (array of doubles) An array of OCS coordinates used to create the polyline vertices. Each vertex is represented with three elements, with the first two being the X and Y coordinates in OCS; the third element is ignored. At least two points (six elements) are required for constructing a polyline object. The array size must be a multiple of three.

Examples VBA: Sub Example_AddPolyline() ' This example creates a polyline in model space. Dim plineObj As AcadPolyline Dim points(0 To 14) As Double ' Define the 2D polyline points points(0) = 1: points(1) = 1: points(2) = 0 points(3) = 1: points(4) = 2: points(5) = 0 points(6) = 2: points(7) = 2: points(8) = 0 points(9) = 3: points(10) = 2: points(11) = 0 points(12) = 4: points(13) = 4: points(14) = 0 ' Create a lightweight Polyline object in model space Set plineObj = ThisDrawing.ModelSpace.AddPolyline(points) ZoomAll End Sub Visual LISP: (vl-load-com) (defun c:Example_AddPolyline();; This example creates a polyline in model space. (setq acadObj (vlax-get-acad-object)) (setq doc (vla-get-ActiveDocument acadObj));; Define the 2D polyline points (setq points (vlax-make-safearray vlax-vbDouble '(0. Gengoroh tagame contracts of the fall 14))) (vlax-safearray-fill points '(1 1 0 1 2 0 2 2 0 3 2 0 4 4 0 ) );; Create a lightweight Polyline object in model space (setq modelSpace (vla-get-ModelSpace doc)) (setq plineObj (vla-AddPolyline modelSpace points)) (vla-ZoomAll acadObj) ).
